G-series Zero Tailing Laser Tube Cutting Machine
| Quantity: | |
|---|---|
-
LT6025G
-
Acme
Product Introduction
The LT-6025G laser pipe cutting machine is independently developed by ACME Laser. The bed is welded by steel plate and steel pipe. The main parts such as the bed chuck are all independently developed, designed and produced by our company. The equipment is equipped with three chucks and is suitable for metal pipes. It can cut various types of metal pipes with diameters of 10-250mm and different shapes. Applicable to industries such as shelves, massage chairs, lamps, sanitary wares.
Product advantages:
High speed
It can perform high-speed and high-quality laser cutting on round tubes, square tubes, rectangular tubes, oval tubes and other special-shaped tubes.
Good flexibility
New product development does not need to reopen the mold, which greatly shortens the development time of new products and reduces development costs.
High precision
Fast speed and high precision, it can realize pipe drilling, cutting, intersecting wire cutting and precision cutting of various special-shaped and complex graphics that are difficult to achieve by conventional processing. After programming on professional pipe nesting software, realize what you see is what you get.
One-time molding
Forming at one time, avoiding multiple processing processes such as traditional cutting and grinding, saves costs and improves efficiency.
Highly recommended
The optical fiber CNC pipe cutting machine is economical in price and powerful in performance. It can finely cut and process a variety of long metal materials such as profile, angle iron, channel steel, H steel, etc. Welcome to consult and purchase.
Product configuration
1. The main machine is welded with 16-20mm carbon steel plate, strictly heat-treated, and the whole plate is cut.
2. The main machine adopts all Japanese Yaskawa motors, with a total of 5 servo motors.
3. Pneumatic support design makes cutting more stable. Use a large stroke automatic centering chuck.
4. The screw holes above 4mm in the whole bed are planed and milled by COLGAR large milling machine.
5. The whole machine adopts electric timing oiler, which can reduce the loss of equipment caused by insufficient lubrication.
Technical Parameters:
Technical Parameters | ||
Model | Laser power | Cutting tube length |
LT-6025G | 1000W-8000W | 6000mm |
Cutting pipe diameter | Cutting tail material | Y-axis stroke |
10-250mm (outer diameter of round tube) | ≥0mm | 6200mm |
X-axis stroke | Z-axis stroke | X, Y-axis positioning accuracy |
260mm | 150mm | ±0.05mm/1000mm |
X, Y axis repeat positioning accuracy | Chuck load | Front chuck load |
±0.03/1000mm | 250KG | Square tube, Rectangular tube, round tube, oval tube, flat tube |
Floor area | Power of the whole machine | Weight of the whole machine |
11585×1916×2250mm (length×width×height) | 20KW | 4 tons |
Power supply | Acceleration | Auxiliary gas |
380v50Hz±10% | 1.2G | Oxygen, nitrogen, air |
Maximum feed rate | Control system | Support file format |
80m/min | Professional laser equipment processing system | IGS (available for drawing by PRO/E.UG, solidworks) |
